Liberty Pultrusions is a manufacturer of high quality, durable pultrusion machines and equipment.

Our machines are built using the best available technology. The company philosophy is to engineer our pultrusion machines to exceed the customers expectations.

In addition to the machine specifications listed below, Liberty Pultrusions can design and build new pultrusion machines to meet your specific product or process requirements. Let our experience in engineering and manufacturing pultrusions and pultrusion equipment benefit your organization.


Pulforce Lab 0804-5000

  • Working window of 8” wide x 4” High
  • Die station: Fixed non-moveable
  • Cooling table: None
  • Dual Automatic Reciprocating pullers
  • Max pulling force: 2-1/2 Ton (5000#)
  • Max Pull speed: 120 in/min
  • Three zone integrated heater control package
  • Electric Supply: 460/480 3-Ph 60Hz
  • Hydaulic Cooling: None
  • Operator controls: All in one compact touch screen controller

Pulforce 0804-8000

  • Nominal Working Window of 8” wide x 4” High
  • Die Station: Fixed non-moveable
  • Cooling Run out table: 8/ft long
  • Dual Automatic Reciprocating Pullers
  • Max Pulling force: 4 Ton (8000#)
  • Max Pull Speed: 120 in/min
  • Pull Speed Regulation: Proportional Hydraulic Velocity Control
  • Maximum Clamping Force: 4 Ton (8000#)
  • Saw Type: Up Cut – Flying Cut off design
  • Manual Selectable Saw Cut-off
  • Three zone integrated heater control package
  • Electrical supply: 460/480 3-Ph 60 Hz
  • Hydraulic system Cooling: Water heat Exchanger
  • Operator Controls: All in one graphics controller

Pulforce 3210

  • Nominal Working window of 32” wide x 10” High
  • Die Station: Moveable
  • Cooling Run out table: 15/ft long
  • Dual Automatic Reciprocating Pullers
  • Max Pulling Force: 15 Tons (30,000#)
  • Max Pull Speed: 60 in/min
  • Pull Speed Regulation: Hydraulic Pressure and Temperature compensated flow control
  • Maximum Clamping Force: 15 Tons (30,000lbs) over 4 cylinders per head (equalized force)
  • Saw type: Automatic Overhead/Crossing with auto cut-off selectable by encoder or paddle switch
  • Three zone integrated heater control package
  • Electrical supply: 460/480 3-Ph 60 Hz
  • Hydraulic System Cooling: Water Heat Exchanger
  • Operator Controls: All in one graphics controller

Pulforce 5012

  • Nominal Working window of 50” wide x 12” High
  • Die Station: Moveable
  • Cooling Run out table: 15/ft long
  • Dual Automatic Reciprocating Pullers
  • Max Pulling Force: 15 Tons (30,000#) Also available upto 25 Tons (50,000#)
  • Max Pull Speed: 60 in/min
  • Pull Speed Regulation: Hydraulic Pressure and Temperature compensated flow control
  • Maximum Clamping Force: 15 Tons (30,000lbs) over 4 cylinders per head (equalized force)
  • Saw type: Automatic Overhead/Crossing with auto cut-off selectable by encoder or paddle switch
  • Three zone integrated heater control package
  • Electrical supply: 460/480 3-Ph 60 Hz
  • Hydraulic System Cooling: Water Heat Exchanger
  • Operator Controls: All in one graphics controller
